Auto name Common wheels parameters |
Factory (Wheels) |
Options (Wheels) |
Tuning (Wheels) |
Factory (tires) |
Options (tires) |
Tuning (tires) |
Acura MDX III (2017 - 2021) 3.5i YD3 Facelift 290 лс
PCD (PCD) 5x120
Hub diameter (Dia,mm) 64.1
Mounting bolt 14x1,5
|
8x18 ET55 |
8x19 ET55 8x20 ET55 8,5x20 ET50 |
245/60 R18 |
245/55 R19 245/50 R20 265/45 R20 |
||
Acura MDX III (2014 - 2016) 3.5i YD3 286 лс
PCD (PCD) 5x114,3
Hub diameter (Dia,mm) 64.1
Mounting bolt 12x1,5
|
8x18 ET55 8x19 ET55 |
8,5x18 ET50 8,5x19 ET50 8x20 ET55 9x20 ET50 |
245/60 R18 245/55 R19 |
265/55 R18 265/50 R19 275/45 R20 245/50 R20 |
||
Acura MDX III (2007 - 2013) 3.7i YD2 300 лс
PCD (PCD) 5x120
Hub diameter (Dia,mm) 64.1
Mounting bolt 14x1,5
|
8x18 ET45 8,5x19 ET45 |
9x19 ET42 8,5x20 ET45 10x20 ET35 |
255/55 R18 255/50 R19 |
255/45 R20 275/45 R19 285/40 R20 |
For an example of size: 8x18 ET55 PCD 5*120 Dia 64.1 , consider the notation for these parameters.
- width - 8 or 8J means the width of the disk shelves in inches
- diameter - 18 or R18 is the installation of the wheel size in inches
- Between the bolt distance (PCD) and number of holes - 5*120 means 5 holes with a distance of 120.
- Et (ET) -55 or ET55 is the distance from the geometric center of the disk shelf to the fitting point to the hub in millimeters. The smaller the flyout, the more the drive is out
- Dia -64.1 the size of the hub in millimeters. Sometimes indicated without a fractional part
- Bolt -14*1,5 diameter and thread pitch of the bolt / nut in millimeters
Using the wheel size example 245/60 R18 , consider what these options mean.
- Width -245 - tire width in millimeters
- Height -60 - this value is specified in percent. The height of the wheel profile in millimeters is calculated as a percentage of the width, for our case this will be245 *60 & # 37; = mm
- Diameter -18 or R18 - tire setting diameter
