Factory wheels and tyres sizes BMW Z3 Roadster (1995 - 2003)

Auto name Common wheels parameters	Factory (Wheels)	Options (Wheels)	Tuning (Wheels)	Factory (tires)	Options (tires)	Tuning (tires)
BMW Z3 Roadster (1998 - 2003) 1.9i E36 117 лс PCD (PCD) 5x120 Hub diameter (Dia,mm) 72.6 Mounting bolt 12x1,5	7x16 ET46	7x15 ET47 7,5x17 ET41 8,5x17 ET41		225/50 R16	205/60 R15 225/45 R17 225/45 R17 245/40 R17
BMW Z3 Roadster (1999 - 2003) 2.0i E36 148 лс PCD (PCD) 5x120 Hub diameter (Dia,mm) 72.6 Mounting bolt 12x1,5	7x16 ET46	7x15 ET47 7,5x17 ET41 8,5x17 ET41		225/50 R16	205/60 R15 225/45 R17 225/45 R17 245/40 R17
BMW Z3 Roadster (2000 - 2003) 2.2i E36 168 лс PCD (PCD) 5x120 Hub diameter (Dia,mm) 72.6 Mounting bolt 12x1,5	7x16 ET46	7x15 ET47 7,5x17 ET41 8,5x17 ET41		225/50 R16	205/60 R15 225/45 R17 225/45 R17 245/40 R17
BMW Z3 Roadster (2000 - 2003) 3.0i E36 228 лс PCD (PCD) 5x120 Hub diameter (Dia,mm) 72.6 Mounting bolt 12x1,5	7x16 ET46	7,5x17 ET41 8,5x17 ET41		225/50 R16	225/45 R17 225/45 R17 245/40 R17
BMW Z3 Roadster (1997 - 2000) 2.8i E36 190 лс PCD (PCD) 5x120 Hub diameter (Dia,mm) 72.6 Mounting bolt 12x1,5	7x16 ET46	7x15 ET47 7,5x17 ET41 8,5x17 ET41		225/50 R16	205/60 R15 225/45 R17 225/45 R17 245/40 R17
BMW Z3 Roadster (1995 - 1999) 1.9i E36 138 лс PCD (PCD) 5x120 Hub diameter (Dia,mm) 72.6 Mounting bolt 12x1,5	7x15 ET47 7x16 ET46	6,5x15 ET47 7,5x17 ET41 8,5x17 ET41		205/60 R15 225/50 R16	205/60 R15 225/45 R17 225/45 R17 245/40 R17
BMW Z3 Roadster (1995 - 1998) 1.8i E36 114 лс PCD (PCD) 5x120 Hub diameter (Dia,mm) 72.6 Mounting bolt 12x1,5	6,5x15 ET47 7x16 ET46	7x15 ET47 7,5x17 ET41 8,5x17 ET41		205/60 R15 225/50 R16	205/60 R15 225/45 R17 225/45 R17 245/40 R17

Wheels parameters:

For an example of size: 7x16 ET46 PCD 5*120 Dia 72.6 , consider the notation for these parameters. - width - 7 or 7J means the width of the disk shelves in inches
- diameter - 16 or R16 is the installation of the wheel size in inches
- Between the bolt distance (PCD) and number of holes - 5*120 means 5 holes with a distance of 120.
- Et (ET) -46 or ET46 is the distance from the geometric center of the disk shelf to the fitting point to the hub in millimeters. The smaller the flyout, the more the drive is out
- Dia -72.6 the size of the hub in millimeters. Sometimes indicated without a fractional part
- Bolt -12*1,5 diameter and thread pitch of the bolt / nut in millimeters

Tyres sizes:

Using the wheel size example 225/50 R16 , consider what these options mean. - Width -225 - tire width in millimeters
- Height -50 - this value is specified in percent. The height of the wheel profile in millimeters is calculated as a percentage of the width, for our case this will be225 *50 & # 37; = mm
- Diameter -16 or R16 - tire setting diameter
