Auto name Common wheels parameters |
Factory (Wheels) |
Options (Wheels) |
Tuning (Wheels) |
Factory (tires) |
Options (tires) |
Tuning (tires) |
|
Honda Civic IX Sedan () 1.4i FB\FG 99 лс
PCD (PCD) 5x114,3
Hub diameter (Dia,mm) 64.1
Mounting bolt 12x1,5
|
6x15 ET45 |
6x16 ET45 6,5x17 ET45 |
195/65 R15 |
195/55 R17 195/60 R16 |
||
|
Honda Civic IX Sedan () 1.8 CNG FB\FG 110 лс
PCD (PCD) 5x114,3
Hub diameter (Dia,mm) 64.1
Mounting bolt 12x1,5
|
6x15 ET45 |
6x16 ET45 6,5x17 ET45 |
195/65 R15 |
195/60 R16 195/55 R17 |
||
|
Honda Civic IX Sedan (2006 - 2016) 1.8i 140 лс
PCD (PCD) 5x114,3
Hub diameter (Dia,mm) 64.1
Mounting bolt 12x1,5
|
6,5x16 ET45 |
6x15 ET45 7x16 ET45 7x17 ET45 7x17 ET50 7,5x18 ET50 |
205/55 R16 |
215/50 R16 215/45 R17 195/65 R15 225/45 R17 225/40 R18 |
||
|
Honda Civic IX Sedan (2002 - 2021) 2.0i
PCD (PCD) 5x114,3
Hub diameter (Dia,mm) 64.1
Mounting bolt 12x1,5
|
6,5x16 ET45 7,5x17 ET45 |
7x16 ET45 7,5x18 ET42 |
205/55 R16 225/45 R17 |
225/50 R16 225/40 R18 |
||
|
Honda Civic IX Sedan (2012 - 2014) 1.4 i-VTEC IX (FK) 98 лс
PCD (PCD) 5x114,3
Hub diameter (Dia,mm) 64.1
Mounting bolt 12x1,5
|
6x15 ET45 6,5x16 ET45 7x17 ET50 |
7,5x18 ET50 |
195/65 R15 205/55 R16 225/45 R17 |
225/40 R18 |
||
|
Honda Civic IX Sedan (2005 - 2021) 1.8 i-VTEC
PCD (PCD) 5x114,3
Hub diameter (Dia,mm) 64.1
Mounting bolt 12x1,5
|
6x15 ET45 6,5x16 ET45 7x17 ET50 |
7,5x18 ET50 |
195/65 R15 205/55 R16 225/45 R17 |
225/40 R18 |
||
|
Honda Civic IX Sedan () 1.4 i-VTEC VIII (FK\FN) 98 лс
PCD (PCD) 5x114,3
Hub diameter (Dia,mm) 64.1
Mounting bolt 12x1,5
|
6,5x16 ET55 |
7x17 ET55 7,5x18 ET55 |
205/55 R16 |
225/45 R17 225/40 R18 |
||
|
Honda Civic IX Sedan (2006 - 2012) 2.0 i-VTEC FN 198 лс
PCD (PCD) 5x114,3
Hub diameter (Dia,mm) 64.1
Mounting bolt 12x1,5
|
7,5x18 ET55 |
7,5x19 ET55 |
225/40 R18 |
225/35 R19 |
For an example of size: 6x15 ET45 PCD 5*114,3 Dia 64.1 , consider the notation for these parameters.
- width - 6 or 6J means the width of the disk shelves in inches
- diameter - 15 or R15 is the installation of the wheel size in inches
- Between the bolt distance (PCD) and number of holes - 5*114,3 means 5 holes with a distance of 114,3.
- Et (ET) -45 or ET45 is the distance from the geometric center of the disk shelf to the fitting point to the hub in millimeters. The smaller the flyout, the more the drive is out
- Dia -64.1 the size of the hub in millimeters. Sometimes indicated without a fractional part
- Bolt -12*1,5 diameter and thread pitch of the bolt / nut in millimeters
Using the wheel size example 195/65 R15 , consider what these options mean.
- Width -195 - tire width in millimeters
- Height -65 - this value is specified in percent. The height of the wheel profile in millimeters is calculated as a percentage of the width, for our case this will be195 *65 & # 37; = mm
- Diameter -15 or R15 - tire setting diameter
