Auto name Common wheels parameters |
Factory (Wheels) |
Options (Wheels) |
Tuning (Wheels) |
Factory (tires) |
Options (tires) |
Tuning (tires) |
|
Mitsubishi Colt VII Cabriolet (2009 - 2012) 1.1i Z2 Fl 74 лс
PCD (PCD) 4x114,3
Hub diameter (Dia,mm) 67.1
Mounting bolt 12x1,5
|
5,5x14 ET46 |
5,5x15 ET46 6x15 ET46 |
175/65 R14 |
185/55 R15 195/50 R15 |
||
|
Mitsubishi Colt VII Cabriolet (2009 - 2012) 1.3i Z2 Fl 94 лс
PCD (PCD) 4x114,3
Hub diameter (Dia,mm) 67.1
Mounting bolt 12x1,5
|
5,5x14 ET46 |
5,5x15 ET46 6x15 ET46 |
175/65 R14 |
185/55 R15 195/50 R15 |
||
|
Mitsubishi Colt VII Cabriolet (2009 - 2012) 1.5 Di-D Z2 Fl 94 лс
PCD (PCD) 4x114,3
Hub diameter (Dia,mm) 67.1
Mounting bolt 12x1,5
|
5,5x14 ET46 |
5,5x15 ET46 6x15 ET46 |
175/65 R14 |
185/55 R15 195/50 R15 |
||
|
Mitsubishi Colt VII Cabriolet (2009 - 2012) 1.5i CZT Z2 Fl 148 лс
PCD (PCD) 4x114,3
Hub diameter (Dia,mm) 67.1
Mounting bolt 12x1,5
|
6,5x16 ET46 |
7x17 ET40 |
205/45 R16 |
205/40 R17 |
||
|
Mitsubishi Colt VII Cabriolet (2009 - 2012) 1.5i Z2 Fl 107 лс
PCD (PCD) 4x114,3
Hub diameter (Dia,mm) 67.1
Mounting bolt 12x1,5
|
5,5x14 ET46 |
6x15 ET46 6,5x16 ET46 |
175/65 R14 |
195/50 R15 205/45 R16 |
||
|
Mitsubishi Colt VII Cabriolet (2004 - 2008) 1.1i Z2 74 лс
PCD (PCD) 4x114,3
Hub diameter (Dia,mm) 67.1
Mounting bolt 12x1,5
|
5,5x14 ET46 |
5,5x15 ET46 6x15 ET46 |
175/65 R14 |
185/55 R15 195/50 R15 |
||
|
Mitsubishi Colt VII Cabriolet (2004 - 2008) 1.3i Z2 94 лс
PCD (PCD) 4x114,3
Hub diameter (Dia,mm) 67.1
Mounting bolt 12x1,5
|
5,5x14 ET46 |
5,5x15 ET46 6x15 ET46 |
175/65 R14 |
185/55 R15 195/50 R15 |
||
|
Mitsubishi Colt VII Cabriolet (2004 - 2008) 1.5 Di-D Z2 94 лс
PCD (PCD) 4x114,3
Hub diameter (Dia,mm) 67.1
Mounting bolt 12x1,5
|
5,5x14 ET46 |
5,5x15 ET46 6x15 ET46 |
175/65 R14 |
185/55 R15 195/50 R15 |
||
|
Mitsubishi Colt VII Cabriolet (2004 - 2008) 1.5i CZT Z2 148 лс
PCD (PCD) 4x114,3
Hub diameter (Dia,mm) 67.1
Mounting bolt 12x1,5
|
6,5x16 ET46 |
7x17 ET40 |
205/45 R16 |
205/40 R17 |
||
|
Mitsubishi Colt VII Cabriolet (2004 - 2008) 1.5i Z2 107 лс
PCD (PCD) 4x114,3
Hub diameter (Dia,mm) 67.1
Mounting bolt 12x1,5
|
5,5x14 ET46 |
6x15 ET46 6,5x16 ET46 |
175/65 R14 |
195/50 R15 205/45 R16 |
||
|
Mitsubishi Colt VII Cabriolet (2006 - 2009) 1.5 MPi Z2 107 лс
PCD (PCD) 4x114,3
Hub diameter (Dia,mm) 67.1
Mounting bolt 12x1,5
|
6x15 ET46 |
6,5x16 ET46 |
195/50 R15 |
205/45 R16 |
||
|
Mitsubishi Colt VII Cabriolet (2006 - 2009) 1.5 T Z2 148 лс
PCD (PCD) 4x114,3
Hub diameter (Dia,mm) 67.1
Mounting bolt 12x1,5
|
6,5x16 ET46 |
7x17 ET44 |
205/45 R16 |
205/40 R17 |
For an example of size: 5,5x14 ET46 PCD 4*114,3 Dia 67.1 , consider the notation for these parameters.
- width - 5,5 or 5,5J means the width of the disk shelves in inches
- diameter - 14 or R14 is the installation of the wheel size in inches
- Between the bolt distance (PCD) and number of holes - 4*114,3 means 4 holes with a distance of 114,3.
- Et (ET) -46 or ET46 is the distance from the geometric center of the disk shelf to the fitting point to the hub in millimeters. The smaller the flyout, the more the drive is out
- Dia -67.1 the size of the hub in millimeters. Sometimes indicated without a fractional part
- Bolt -12*1,5 diameter and thread pitch of the bolt / nut in millimeters
Using the wheel size example 175/65 R14 , consider what these options mean.
- Width -175 - tire width in millimeters
- Height -65 - this value is specified in percent. The height of the wheel profile in millimeters is calculated as a percentage of the width, for our case this will be175 *65 & # 37; = mm
- Diameter -14 or R14 - tire setting diameter
