Factory wheels and tyres sizes Mitsubishi Lancer IX Sedan (2000 - 2010)

Auto name Common wheels parameters	Factory (Wheels)	Options (Wheels)	Tuning (Wheels)	Factory (tires)	Options (tires)	Tuning (tires)
Mitsubishi Lancer IX Sedan (2009 - 2010) 1.3i Classic CS IX Facelift 80 лс PCD (PCD) 4x114,3 Hub diameter (Dia,mm) 67.1 Mounting bolt 12x1,5	6x15 ET46	6x16 ET46		195/60 R15	195/50 R16 195/55 R16
Mitsubishi Lancer IX Sedan (2003 - 2010) 1.3i CS IX Facelift 80 лс PCD (PCD) 4x114,3 Hub diameter (Dia,mm) 67.1 Mounting bolt 12x1,5	5,5x14 ET46 6x15 ET46	6x16 ET46		185/65 R14 195/60 R15	195/50 R16
Mitsubishi Lancer IX Sedan (2009 - 2010) 1.6i Classic CS IX Facelift 97 лс PCD (PCD) 4x114,3 Hub diameter (Dia,mm) 67.1 Mounting bolt 12x1,5	6x15 ET46	6x16 ET46 6,5x16 ET46		195/60 R15	195/50 R16 205/50 R16
Mitsubishi Lancer IX Sedan (2003 - 2010) 1.6i CS IX Facelift 97 лс PCD (PCD) 4x114,3 Hub diameter (Dia,mm) 67.1 Mounting bolt 12x1,5	6x15 ET46 6x16 ET46	6,5x16 ET46		195/60 R15 195/50 R16	205/50 R16
Mitsubishi Lancer IX Sedan (2007 - 2012) 2.0 D CY X 138 лс PCD (PCD) 5x114,3 Hub diameter (Dia,mm) 67.1 Mounting bolt 12x1,5	6,5x16 ET46	6,5x17 ET46 7x18 ET46		205/60 R16	215/50 R17 215/45 R18
Mitsubishi Lancer IX Sedan (2008 - 2017) 2.0 T CY X 237 лс PCD (PCD) 5x114,3 Hub diameter (Dia,mm) 67.1 Mounting bolt 12x1,5	7x18 ET46	7,5x18 ET48 8x19 ET42		215/45 R18	235/40 R18 235/35 R19
Mitsubishi Lancer IX Sedan (2003 - 2010) 2.0i CS IX Facelift 133 лс PCD (PCD) 5x114,3 Hub diameter (Dia,mm) 67.1 Mounting bolt 12x1,5	6x16 ET46	6,5x16 ET46 7x17 ET46		195/50 R16	205/50 R16 205/45 R17
Mitsubishi Lancer IX Sedan (2007 - 2017) 2.0i CY X 148 лс PCD (PCD) 5x114,3 Hub diameter (Dia,mm) 67.1 Mounting bolt 12x1,5	6,5x16 ET46	7x17 ET46 7x18 ET46		205/60 R16	215/50 R17 215/45 R18
Mitsubishi Lancer IX Sedan (2001 - 2003) 2.0i ES CS IX 120 лс PCD (PCD) 4x100 Hub diameter (Dia,mm) 56.1 Mounting bolt 12x1,5	5,5x14 ET46	6x15 ET46 6,5x16 ET46		185/65 R14	185/60 R15 195/55 R15 195/50 R16
Mitsubishi Lancer IX Sedan (2001 - 2003) 2.0i LS CS IX 120 лс PCD (PCD) 4x114,3 Hub diameter (Dia,mm) 67.1 Mounting bolt 12x1,5	6x15 ET46	6x16 ET46 6,5x16 ET46 7x17 ET46		195/60 R15	205/45 R17 195/55 R16 205/50 R16
Mitsubishi Lancer IX Sedan (2001 - 2003) 2.0i OZ CS IX 120 лс PCD (PCD) 4x114,3 Hub diameter (Dia,mm) 67.1 Mounting bolt 12x1,5	6x15 ET46	6x15 ET46 6,5x16 ET46 7x17 ET46		195/60 R15	195/55 R15 205/50 R16 205/45 R17
Mitsubishi Lancer IX Sedan () 1.3i CK\CM VIII 89 лс PCD (PCD) 4x100 Hub diameter (Dia,mm) 56.1 Mounting bolt 12x1,5	5x13 ET46	5,5x14 ET46 5,5x15 ET46		175/70 R13	185/60 R14 185/55 R15
Mitsubishi Lancer IX Sedan () 1.6i CK\CM VIII 111 лс PCD (PCD) 4x100 Hub diameter (Dia,mm) 56.1 Mounting bolt 12x1,5	5x13 ET46	5,5x14 ET46 6x15 ET46		175/70 R13	185/60 R14 195/50 R15
Mitsubishi Lancer IX Sedan (2008 - 2015) 2.0 T CA X 291 лс PCD (PCD) 5x114,3 Hub diameter (Dia,mm) 67.1 Mounting bolt 12x1,5	8,5x18 ET38			245/40 R18
Mitsubishi Lancer IX Sedan (2005 - 2007) 2.0 T 291 лс PCD (PCD) 5x114,3 Hub diameter (Dia,mm) 67.1 Mounting bolt 12x1,5		8x17 ET38 8x18 ET38 8,5x18 ET38			245/40 R18 235/45 R17 235/40 R18
Mitsubishi Lancer IX Sedan (2003 - 2005) 2.0 T 271 лс PCD (PCD) 5x114,3 Hub diameter (Dia,mm) 67.1 Mounting bolt 12x1,5		8x17 ET38 8x18 ET38			235/45 R17 225/45 R17 235/40 R18
Mitsubishi Lancer IX Sedan (2007 - 2010) 2.0i 157 лс PCD (PCD) 5x114,3 Hub diameter (Dia,mm) 67.1 Mounting bolt 12x1,5	6,5x16 ET46	7x17 ET46 7x18 ET46		205/60 R16	215/50 R17 215/45 R18

Wheels parameters:

For an example of size: 6x15 ET46 PCD 4*114,3 Dia 67.1 , consider the notation for these parameters. - width - 6 or 6J means the width of the disk shelves in inches
- diameter - 15 or R15 is the installation of the wheel size in inches
- Between the bolt distance (PCD) and number of holes - 4*114,3 means 4 holes with a distance of 114,3.
- Et (ET) -46 or ET46 is the distance from the geometric center of the disk shelf to the fitting point to the hub in millimeters. The smaller the flyout, the more the drive is out
- Dia -67.1 the size of the hub in millimeters. Sometimes indicated without a fractional part
- Bolt -12*1,5 diameter and thread pitch of the bolt / nut in millimeters

Tyres sizes:

Using the wheel size example 195/60 R15 , consider what these options mean. - Width -195 - tire width in millimeters
- Height -60 - this value is specified in percent. The height of the wheel profile in millimeters is calculated as a percentage of the width, for our case this will be195 *60 & # 37; = mm
- Diameter -15 or R15 - tire setting diameter
