Factory wheels and tyres sizes Nissan 370Z I Coupe (2009 - 2024)

Auto name Common wheels parameters	Factory (Wheels)	Options (Wheels)	Tuning (Wheels)	Factory (tires)	Options (tires)	Tuning (tires)
Nissan 370Z I Coupe (2013 - 2020) 3.7 Nismo I Restyling 350 лс PCD (PCD) 5x114,3 Hub diameter (Dia,mm) 66.1 Mounting bolt 12x1,25	9,5x19 ET40 10,5x19 ET23			245/40 R19 285/35 R19
Nissan 370Z I Coupe (2013 - 2020) 3.7i 332 лс PCD (PCD) 5x114,3 Hub diameter (Dia,mm) 66.1 Mounting bolt 12x1,25	8x18 ET43 9x18 ET15 9x19 ET47 10x19 ET30			225/50 R18 245/45 R18 245/40 R19 275/35 R19
Nissan 370Z I Coupe (2009 - 2012) 3.7 Nismo I 350 лс PCD (PCD) 5x114,3 Hub diameter (Dia,mm) 66.1 Mounting bolt 12x1,25	9,5x19 ET40 10,5x19 ET23			245/40 R19 285/35 R19
Nissan 370Z I Coupe (2009 - 2012) 3.7i 323 лс PCD (PCD) 5x114,3 Hub diameter (Dia,mm) 66.1 Mounting bolt 12x1,25	8x18 ET43 9x18 ET15	9x19 ET47 10x19 ET30		225/50 R18 245/45 R18	245/40 R19 275/35 R19

Wheels parameters:

For an example of size: 9,5x19 ET40 PCD 5*114,3 Dia 66.1 , consider the notation for these parameters. - width - 9,5 or 9,5J means the width of the disk shelves in inches
- diameter - 19 or R19 is the installation of the wheel size in inches
- Between the bolt distance (PCD) and number of holes - 5*114,3 means 5 holes with a distance of 114,3.
- Et (ET) -40 or ET40 is the distance from the geometric center of the disk shelf to the fitting point to the hub in millimeters. The smaller the flyout, the more the drive is out
- Dia -66.1 the size of the hub in millimeters. Sometimes indicated without a fractional part
- Bolt -12*1,25 diameter and thread pitch of the bolt / nut in millimeters

Tyres sizes:

Using the wheel size example 245/40 R19 , consider what these options mean. - Width -245 - tire width in millimeters
- Height -40 - this value is specified in percent. The height of the wheel profile in millimeters is calculated as a percentage of the width, for our case this will be245 *40 & # 37; = mm
- Diameter -19 or R19 - tire setting diameter
