Factory wheels and tyres sizes Peugeot 406 Coupe (1997 - 2004)

Factory wheels and tyres sizes Peugeot 406 Coupe (1997 - 2004)
Auto name
Common wheels parameters
Factory
(Wheels)
Options
(Wheels)
Tuning
(Wheels)
Factory
(tires)
Options
(tires)
Tuning
(tires)
Peugeot 406 Coupe (2000 - 2004) 1.8i X2 115 лс
PCD (PCD) 4x108
Hub diameter (Dia,mm) 65.1
Mounting bolt 12x1,25
 6x15 ET18
6,5x15 ET20
6,5x16 ET20
7x17 ET15
195/65 R15
205/60 R15
 205/55 R16
205/50 R17
Peugeot 406 Coupe (2000 - 2004) 2.0 HDi X2 107 лс
PCD (PCD) 4x108
Hub diameter (Dia,mm) 65.1
Mounting bolt 12x1,25
 6x15 ET18
6,5x15 ET20
6,5x16 ET20
7x17 ET15
195/65 R15
205/60 R15
 215/50 R17
205/55 R16
Peugeot 406 Coupe (2000 - 2004) 2.0i X2 138 лс
PCD (PCD) 4x108
Hub diameter (Dia,mm) 65.1
Mounting bolt 12x1,25
 6x15 ET18
6,5x15 ET20
7x16 ET15
7x17 ET15
195/65 R15
205/60 R15
 215/55 R16
215/50 R17
Peugeot 406 Coupe (2000 - 2004) 2.2 HDi X2 131 лс
PCD (PCD) 4x108
Hub diameter (Dia,mm) 65.1
Mounting bolt 12x1,25
 6x15 ET18
6,5x15 ET20
7x16 ET18
7,5x17 ET12
195/65 R15
205/60 R15
 225/45 R17
215/55 R16
Peugeot 406 Coupe (1999 - 2004) 2.2i X2 156 лс
PCD (PCD) 4x108
Hub diameter (Dia,mm) 65.1
Mounting bolt 12x1,25
 6,5x15 ET20
7x16 ET12
7x16 ET15
7,5x17 ET12
205/60 R15
205/55 R16
 215/55 R16
225/45 R17
Peugeot 406 Coupe (1995 - 1999) 1.6i X2 87 лс
PCD (PCD) 4x108
Hub diameter (Dia,mm) 65.1
Mounting bolt 12x1,25
 5,5x14 ET24
6x15 ET18
5,5x15 ET20
6,5x16 ET20
185/70 R14
195/65 R15
 195/55 R16
185/65 R15
Peugeot 406 Coupe (1995 - 1999) 1.8i 16V X2 107 лс
PCD (PCD) 4x108
Hub diameter (Dia,mm) 65.1
Mounting bolt 12x1,25
 6x15 ET18
6,5x15 ET20
6x16 ET20
6,5x17 ET18
195/65 R15
205/60 R15
 195/60 R16
205/50 R17
Peugeot 406 Coupe (1995 - 1999) 1.8i X2 89 лс
PCD (PCD) 4x108
Hub diameter (Dia,mm) 65.1
Mounting bolt 12x1,25
 5,5x14 ET24
6x15 ET18
6x16 ET20
6,5x16 ET20
185/70 R14
195/65 R15
 205/50 R16
195/55 R16
Peugeot 406 Coupe (1995 - 1999) 1.9 TD X2 89 лс
PCD (PCD) 4x108
Hub diameter (Dia,mm) 65.1
Mounting bolt 12x1,25
 5,5x14 ET24
6x15 ET18
6,5x15 ET20
7x16 ET15
185/70 R14
195/65 R15
 205/65 R15
215/55 R16
Peugeot 406 Coupe (1996 - 1999) 2.0 T X2 145 лс
PCD (PCD) 4x108
Hub diameter (Dia,mm) 65.1
Mounting bolt 12x1,25
 6x15 ET18
6,5x16 ET20
6,5x16 ET20
7x17 ET18
195/65 R15
205/60 R16
 205/55 R16
215/50 R17
Peugeot 406 Coupe (1997 - 1999) 2.0i X2 134 лс
PCD (PCD) 4x108
Hub diameter (Dia,mm) 65.1
Mounting bolt 12x1,25
 6x15 ET18
6,5x15 ET20
6,5x16 ET20
7x17 ET18
195/65 R15
205/60 R15
 205/55 R16
205/50 R17
Peugeot 406 Coupe (1995 - 1999) 2.1 TD X2 107 лс
PCD (PCD) 4x108
Hub diameter (Dia,mm) 65.1
Mounting bolt 12x1,25
 6x15 ET18
6,5x15 ET20
7x16 ET18
7,5x17 ET15
195/65 R15
205/60 R15
 225/45 R17
215/55 R16

Wheels parameters:

For an example of size: 6x15 ET18 PCD 4*108 Dia 65.1 , consider the notation for these parameters. - width - 6 or 6J means the width of the disk shelves in inches
- diameter - 15 or R15 is the installation of the wheel size in inches
- Between the bolt distance (PCD) and number of holes - 4*108 means 4 holes with a distance of 108.
- Et (ET) -18 or ET18 is the distance from the geometric center of the disk shelf to the fitting point to the hub in millimeters. The smaller the flyout, the more the drive is out
- Dia -65.1 the size of the hub in millimeters. Sometimes indicated without a fractional part
- Bolt -12*1,25 diameter and thread pitch of the bolt / nut in millimeters

Tyres sizes:

Using the wheel size example 195/65 R15 , consider what these options mean. - Width -195 - tire width in millimeters
- Height -65 - this value is specified in percent. The height of the wheel profile in millimeters is calculated as a percentage of the width, for our case this will be195 *65 & # 37; = mm
- Diameter -15 or R15 - tire setting diameter
