Auto name Common wheels parameters |
Factory (Wheels) |
Options (Wheels) |
Tuning (Wheels) |
Factory (tires) |
Options (tires) |
Tuning (tires) |
|
Renault Megane III Cabriolet (2002 - 2020) 1.5 dCi
PCD (PCD) 5x114,3
Hub diameter (Dia,mm) 66.1
Mounting bolt 12x1,5
|
6x15 ET35 |
6,5x16 ET41 7x17 ET43 7,5x18 ET46 |
195/65 R15 |
205/55 R16 205/50 R17 225/40 R18 |
||
|
Renault Megane III Cabriolet (2000 - 2012) 1.9 dCi
PCD (PCD) 5x114,3
Hub diameter (Dia,mm) 66.1
Mounting bolt 12x1,5
|
6,5x15 ET43 |
6,5x16 ET47 6,5x17 ET47 7x17 ET49 |
195/65 R15 205/65 R15 |
205/55 R16 205/60 R16 205/55 R17 205/50 R17 |
||
|
Renault Megane III Cabriolet (2002 - 2012) 2.0 dCi
PCD (PCD) 5x114,3
Hub diameter (Dia,mm) 66.1
Mounting bolt 12x1,5
|
6,5x16 ET47 |
6,5x17 ET47 7x17 ET49 7,5x17 ET49 7,5x18 ET49 |
205/55 R16 205/60 R16 |
205/55 R17 205/50 R17 225/45 R17 225/40 R18 |
For an example of size: 6x15 ET35 PCD 5*114,3 Dia 66.1 , consider the notation for these parameters.
- width - 6 or 6J means the width of the disk shelves in inches
- diameter - 15 or R15 is the installation of the wheel size in inches
- Between the bolt distance (PCD) and number of holes - 5*114,3 means 5 holes with a distance of 114,3.
- Et (ET) -35 or ET35 is the distance from the geometric center of the disk shelf to the fitting point to the hub in millimeters. The smaller the flyout, the more the drive is out
- Dia -66.1 the size of the hub in millimeters. Sometimes indicated without a fractional part
- Bolt -12*1,5 diameter and thread pitch of the bolt / nut in millimeters
Using the wheel size example 195/65 R15 , consider what these options mean.
- Width -195 - tire width in millimeters
- Height -65 - this value is specified in percent. The height of the wheel profile in millimeters is calculated as a percentage of the width, for our case this will be195 *65 & # 37; = mm
- Diameter -15 or R15 - tire setting diameter
